If you want to increase both voltage and amperage you could connect multiple batteries in both series and parallel. In this example we will.
Simple Ways To Connect Batteries In A Series 12 Steps
How to connect 4 batteries in series. To connect batteries in a series use jumper wire to connect the negative terminal of the first battery to the positive terminal of the second battery. Repeat the connection process until all of the batteries you want to connect in a series are connected by jumper cables. Use another set of cables to connect the open positive and negative terminals to your application. Okay youre going to need some batteries to wire together and some way to wire them together. Following this example where there are two 12v 200ah batteries connected in series we will have a total voltage of 24v volts and an unchanged capacity of 200ah ampere hour. Make a series of more than two batteries by connecting the terminals.
Many commercial batteries which offer higher voltages are made by connecting lower voltage cells in series. Each battery you connect in series increases the voltage of the battery bank. Wiring two batteries in series. For example a 6 volt battery could be produced by connecting four 15 volt cells together in series. In this video jay and randy will show you how to properly series parallel and series parallel four 12 volt batteries together. You will need at least four batteries to build this complex configuration.
Most batteries are rated at 2v 6v or 12v so you will need to connect them in series in order to reach the voltage you require. Take jumper cables and clamp around the positive terminal of one battery and the negative of the battery next to it. Wiring two batteries in parallel. As in the diagram above two 6 volt 45 ah batteries wired in series are capable of providing 12 volts 6 volts 6 volts and 45 amp hours. How to wire batteries in series or in parallel step 1. The series connection of two identical batteries allows to get twice the rated voltage of the individual batteries keeping the same capacity.
More power. The basic concept when connecting in series is that you add the voltages of the batteries together but the amp hour capacity remains the same. If you already have two sets of batteries connected in parallel you can wire them together to form a series connection. Connecting batteries in series means connecting the terminal of the first battery to the terminal of the next battery.
